Circulation pump for Wilo Top-Z hot water system (flange, gray cast iron)
Short information
Max. flow: 16.0 - 65.0 m³/h Max. head: 6.0 - 9.0 m.aq. Art. Pipe flange connection: DN 40 - DN 80 Max. operating pressure: 6 - 10 bar Max. power consumption: 320 - 1440 W Temperature range: 0...+80 °C
SKU:
2046632sbor
| Наименование | Краткая информация | Артикул | Price | Qty | Add to Cart |
|---|---|---|---|---|---|
| DHW circulation pump Wilo Top-Z 40/7 DM | Max. flow rate: 16.00 m³/h Max. head: 6.00 m w.c. Art. Pipe flange connection: DN 40 Max. power consumption: 320 W | 2046632 |
₴33,120.00
|
||
| DHW circulation pump Wilo Top-Z 40/7 EM | Max. flow rate: 16.00 m³/h Max. head: 6.00 m w.c. Art. Pipe flange connection: DN 40 Max. power consumption: 340 W | 2046631 |
₴35,880.00
|
||
| DHW circulation pump Wilo Top-Z 50/7 DM | Max. flow: 25.00 m³/h Max. head: 7.00 m w.c. Art. Pipe flange connection: DN 50 Max. power consumption: 680 W | 2046633 |
₴47,040.00
|
||
| DHW circulation pump Wilo Top-Z 65/10 DM | Max. flow: 42.00 m³/h Max. head: 9.00 m w.c. Art. Pipe flange connection: DN 65 Max. power consumption: 1050 W | 2046634 |
₴80,520.00
|
||
| DHW circulation pump Wilo Top-Z 80/10 DM | Max. flow: 65.00 m³/h Max. head: 9.00 m w.c. Art. Pipe flange connection: DN 80 Max. power consumption: 1440 W | 2046635 |
₴97,680.00
|
||
| DHW circulation pump Wilo Top-Z 80/10 DM | Max. flow: 65.00 m³/h Max. head: 9.00 m w.c. Art. Pipe flange connection: DN 80 Max. power consumption: 1440 W | 2046636 |
₴97,680.00
|
Details
Details
Circulation pump for Wilo Top-Z hot water system (flanged, gray cast iron)
Wilo TOP-Z circulation pumps circulate water in heating, hot water and floor heating systems. Wilo TOP-Z circulation pumps are quite compact and lightweight, installed directly on the pipeline and operate almost silently. Suitable for systems of almost all private houses, not easy to install and have a long service life. The installation of the Wilo TOP-Z electronic high-efficiency pump saves up to 90% of energy compared to an unregulated circulation pump. If, however, the Wilo TOP-Z pump is used in the hot water supply system, then the energy savings compared to standard circulation pumps will be 80%.
Equipment and functions of Wilo TOP-Z circulation pumps:
- manual power adjustment with 3 speed settings
- Wilo pumps TOP - Z EM with single-phase motor:
- P 2 up to 90 W: Integrated winding protection against overheating
- P 2 = 180 W: Complete motor protection by winding safety contact in combination with tripping device
- Wilo pumps TOP - Z DM with 3-phase motor:
- P 2 up to 90 W: Integrated winding protection against overheating
- P 2 ≥ 180 W: Complete motor protection with integrated electronic tripping system
- fault indicator
- contact for generalized fault signaling
- control indicator for direction of rotation
- connection to a 3-phase 230 V mains supply with optional switching plug
- Wilo pump housing TOP - Z bronze or gray cast iron (may be stainless steel depending on the type)
- combined flange PN 6/PN 10 (for DN 40 – DN 65)
- thermal insulation for use in heating systems
- Additional functions when retrofitting with protection module C:
- fault signaling SSM as potential-free NC contact;
- operation signaling SBM as potential-free normally open contact
- control input "Off" by priority" with an external potential-free contact (NC contact)
- blockage detection
- complete motor protection for the Wilo pump TOP - Z built-in disconnect device
- Wilo double pump control system (two pumps installed in parallel): Master/standby operating mode (automatic pump changeover on fault/timer)
Equipment and material of Wilo TOP-Z circulation pumps:
- for Wilo pumps TOP - Z with flange connection: Flange versions
- standard version for pumps DN 40 - DN 65: combination flange PN 6/10 (flange PN 16 according to EN 1092-2) for counter flanges PN 6 and PN 16,
- standard version for DN 80 pumps: flange PN 6 (designed PN 16 according to EN 1092-2) for counter flange PN 6,
- special version for pumps DN 40 - DN 80: flange PN 16 (according to EN 1092-2) for counter flange PN 16
- cable entry possible on both sides (only for single-phase and three-phase pumps with P 2 ≥180 W)
- serial thermal insulation
- Wilo pump housing TOP - Z : stainless steel / bronze / gray cast iron (depending on type)
- impeller: synthetic material
- shaft: stainless steel/ceramic (depending on type)
- bearings: graphite impregnated with synthetic resin
Wilo TOP-Z 40/7 |
 |
Wilo TOP-Z 50/7 |
 |
Wilo TOP-Z 65/10 |
 |
Wilo TOP-Z 80/10 |
 |
 |
